Specification
1. Type name: Volumetric Piston Type2. Size.: DN15 to 20mm( 1/2" -3/4"), Available for cold water(40°C)
3. Standard :ISO 4064, Class C standard
4. Material: Brass
5. Easy for interchange & maintenance
6. Horizontal installation
Working Conditions
Water temperature<50ºC (Hot water meter<90°C)
Water pressure <1MPa(PN: 1.6Pa/16bar)
<0.1 MPa
<0.063MPa(R80/R100)
<0.063MPa(R80/R100)
Accuracy
From minimum flow-rate (Qmin) inclusive, to transitional flow-rate (Qt) Exclusive +-5%
From transitional flow-rate (Qt) Inclusive,to overload flow rate (Qs) Exclusive +- 2%
Technical Details
|
Meter Size DN (mm)
|
Class
|
Qs
Overload Flow |
Qp
Nominal Flow |
Qt
Transitional Flow |
Qmin
Min Flow |
Min
Reading |
Max
Reading |
|
m³/h
|
L/h
|
m³
|
|||||
|
15
|
C
|
3
|
1.5
|
22.5
|
15
|
0.0001
|
99999
|
|
20
|
C
|
5
|
2.5
|
37.5
|
25
|
0.0001
|
99999
|
Installation
Installation requirements: Meter should be installed in horizontal position with the register face upwards Pipe line must be flushed before installation The meter should be constantly full of water during operation
Feature
1. Volumetric meter.on principle of rotary piston, according to Grade C of IS004064 standard(R=160)
2. High sensitivity,can count to the minimum flow rate of 2L/h.
3. The meter can be installed in any position,horizontally,vertically,or inclined pipelines,maintaining optimunm performance with
no loss of accuracy.
4.The numerical wheel of register/conter special liquid sealed,ensures a long term clear reading.
5. Moving parts apply optimum materials.and ensure astable performance.
6. Spray plastics of casing,beautiful and durable.
7. The body for option:Brass,plastic(Nylon)body of Ceramal Aluminium Alloy complex material
2. High sensitivity,can count to the minimum flow rate of 2L/h.
3. The meter can be installed in any position,horizontally,vertically,or inclined pipelines,maintaining optimunm performance with
no loss of accuracy.
4.The numerical wheel of register/conter special liquid sealed,ensures a long term clear reading.
5. Moving parts apply optimum materials.and ensure astable performance.
6. Spray plastics of casing,beautiful and durable.
7. The body for option:Brass,plastic(Nylon)body of Ceramal Aluminium Alloy complex material
