Flexible Universal Joint
Details:
Ductile Iron Universal Coupling According to ISO2531&EN545
Size Range: DN40-DN600
Pressure: PN10/16
Bolts and Nuts material:Carbon Steel
Coating: Fusion Bonded Epoxy coating
Use: This kind of couplings can be used for ductile iron or PVC pipes.
Features
For STEEL . DI , UPVC,PPR,CI AND AC pipes or almost any other rigid pipe material . In the form of wide range (up to 23mm) couplings , are designed to joint pipes of various outside diameters with the same of different nominal bore . The ability of universal coupling to joint dissimilar pipe materials is a bonus feature in both repair or permanent situation .
Direction for use
The product is easy to install and easy to disassemble. Set the connector evenly in the joint position of two different pipes and then tighten the screws.Is a very flexible coupling system used to assemble almost all types of piping materials and to repair old piping systems.
Material Specifications:
Body | Ductile Iron GGG50/40 |
End Ring | Ductile Iron GGG50/40 |
Rubber Seal | Rubber |
Bolt &Nut | Dacromet Coated Steel |
Cap | Plastic |
Flexible Universal Joint
